【Scope of application】
It is used to test the air permeability of various sheet materials such as coated fabrics, filter paper, filter media, and plastics.
【Standards compliant】
GB/T5453, GB/T13764, ISO9237, ISO7231, ISO5636, BS5636, ASTM D737, DIN 53887, JIS L1096, BS5636
【technical parameter】
1. Pressure range: 0～4000Pa self-set pressure drop
2. Measurable air permeability: 0.1～12000mm/s
3. Measurement error: ≤±2%
4. Measurable fabric thickness: ≤15mm
5. Suction volume adjustment: data feedback dynamic adjustment
6. Sample area fixed value circle: 5cm2; 20cm2; 50cm2; 100cm2; optional
7. Fixed value circle of sample diameter: Ф50mm(≈19.6cm2) Ф70mm(≈38.5cm2)
8. Nozzles: 11 in total
9. Data processing capacity: ≤1000 tests
10. Data output: high-definition touch screen display; built-in micro printer;
11. Power supply: AC 220V±10V 50Hz
12. Power consumption: 2000W
13. Weight: 80Kg
14. Shape: 600×700×1100mm(L×W×H)
